Grundfos MTB 65-200/183 A-F-A-BQQE Submersible pump 98768038

    6,613.93 € 6,613.93 € 6613.93 EUR

    6,613.93 €

    Option not available

    Diese Kombination existiert nicht.

    Add to cart

    EAN number: 5712601113038 | Nominal flow rate: 60 m³/h | Nominal head: 32 m | Maximum ambient temperature: 60 °C | Media temperature range: 0 ... 90 °C | Mains frequency: 50 Hz | Rated voltage: 3 x 380-415D/660-690Y V


    In the profluid store simply buy online - for larger orders or scale discounts please contact us for an individual offer.

    The offer is exclusively for professionals.

    Grundfos 98768038 Submersible pump with semi-open free-flow impeller MTB 65-200/183 A-F-A-BQQE

    Product Number: 98768038

    EAN Number: 5712601113038


    Single-stage close-coupled pump with cast iron casing and impeller and directly flanged standard motor (EFF2). The semi-open impeller is designed for pumping abrasive media with a max. particle size of up to 20mm. Main areas of application: Pump-back stations at WZM Cleaning machines Parts cleaning machines Waste water technology and many more

    Accessories


    No installation kit

    Tech. Details

    Product information
    Product informationProduct name.MTB 65-200/183 A-F-A-BQQE
    Product number
    98768038
    EAN number
    5712601113038
    Customs tariff no.
    84137051
    Country of origin
    HU
    Electrical data
    Power consumption P1.
    Mains frequency 50 Hz
    Dimensioning voltage. 3 x 380-415D/660-690Y V.
    Service Factor K.A.
    Designated current. 20.8-19.8/12.0-11.8 A
    Start-up current 660-780 %
    nominal speed. 2940-2950 1/min
    Efficiency of the engine at full load. 91.2 %
    Protection class (according to IEC 34-5) 55 Dust/Jetting
    Heat class (IEC 85) F
    Installed motor protection. PTC
    Std. motor K.A.
    Construction size. K.A.
    Multiple plug. K.A.
    IE efficiency class 50Hz. K.A.
    Rated power - P2 K.A.
    Suitable for 50/60 Hz. K.A.
    number of phases K.A.
    Maximum current consumption K.A.
    Nominal speed, 50 Hz. K.A.
    Efficiency. IE3 91,2%
    Isolation class (IEC 85) K.A.
    Motor protection K.A.
    Installation
    Maximum ambient temperature. 60 °C
    Pressure port connection. DN 65
    Insertion length. K.A.
    Code for pipe connection. F
    Size of the pressure port. K.A.
    Depth of immersion. K.A.
    Max. Pressure at given temperature K.A.
    Connection type K.A.
    Technical data
    nominal flow rate. 60 m³/h
    Nominal head 32 m
    Maximum funding K.A.
    Test mark on the type plate. K.A.
    Pump version. A
    Model. K.A.
    Cable grommet. K.A.
    GLRD Code K.A.
    ISO acceptance class. K.A.
    Number of impeller chambers. K.A.
    No. of wheels. K.A.
    Shipment medium Media temperature range. 0 ... 90 °C
    Medium temperature during operation
    20 °C
    Density 998.2 kg/m³
    Materials Pump casing. Grey cast iron.
    Impeller
    1
    Material type key. A
    Wheel material according to ASTM. K.A.
    Pump casing. K.A.
    Type of control
    Position of the terminal box. K.A.
    Others Net Weight 151 kg
    Gross weight. 182 kg
    Shipping volume. 0.724 m³
    Country of origin. HU
    Customs Tariff No. 84137051
    Minimum Efficiency Index MEI ≥. K.A.
